| Per trovare il codice del prodotto desiderato, unire la sigla del raccordo (es. FL3, FL345, FL6...) alla colonna "Codice PBC". |
|
| Codice PBC | diametro tubo | filetto F |
D | A | B | C | G | E |
| ....-13-13 | 1/2" | 1/2" | 31.7 | 50 | 23 | 64 | 44 | 39 | | ....-19-13 | 1/2" | 3/4" | 41.3 | 55 | 28 | 69 | 51 | 39 | | ....-13-16 | 5/8" | 1/2" | 31.7 | 50 | 26 | 60 | 50 | 49 | | ....-19-16 | 5/8" | 3/4" | 41.3 | 51 | 30 | 66 | 59 | 49 | | ....-13-19 | 3/4" | 1/2" | 31.7 | 53 | 28 | 64 | 53 | 57 | | ....-19-19 | 3/4" | 3/4" | 41.3 | 53 | 32 | 70 | 62 | 57 | | ....-25-19 | 3/4" | 1" | 47.6 | 64 | 35 | 74 | 67 | 57 | | ....-19-25 | 1" | 3/4" | 41.3 | 64 | 35 | 86 | 64 | 77 | | ....-25-25 | 1" | 1" | 47.6 | 66 | 32 | 89 | 69 | 77 | | ....-32-25 | 1" | 1 1/4" | 54 | 71 | 36 | 94 | 76 | 77 | | ....-25-32 | 1 1/4" | 1" | 47.6 | 66 | 36 | 100 | 87 | 89 | | ....-32-32 | 1 1/4" | 1 1/4" | 54 | 67 | 43 | 104 | 93 | 89 | | ....-38-32 | 1 1/4" | 1 1/2" | 63.5 | 78 | 44 | 107 | 97 | 89 | | ....-38-38 | 1 1/2" | 1 1/2" | 63.5 | 78 | 41 | 118 | 111 | 101 | | ....-50-38 | 1 1/2" | 2" | 79.4 | 73 | 52 | 119 | 126 | 101 | | ....-50-50 | 2" | 2" | 79.4 | 73 | 59 | 153 | 128 | 144 |
|
